 Modify Hole Fillets

This function can allow user to modify radius of existing fillet with different values for concave and convex fillet.

To change the fillet radius in a sketch:

1.       Go to edit sketch mode

2.       Chain-select a connected profile

3.       Click  and input the fillet radius

4.    Click OK
