My Blanks

Unfold ››
Parent Previous Next

My Blanks

My Blanks is a new intermediate stage before strip layout design. It allows user to touch up the blank geometries. The latest blank will be used in strip layout design. My Blank is not associated to the part and it is the only disadvantage. .

Use of My Blank



     Hole size tolerance can be adjusted for tool wear …

     Prepare a clean blank for cutting punch design

     Minor part modification

To create My Blank:

  1. RM select My Blanks and click Add My Blank
  2. RM select My Blank 1 and click Edit Sketch
